PP PE Material None

Basic Info.

Model NO.	PPSG
Usage	Dust Filter, Liquid Filter
Filtration Grade	PRE Filter
Filter Bag Environment	Temperature
Cartridge Installation	Vertical Lifting
Construction	Single Layer
Seam Treatment	Fused Seam, Stitched Seam
Sealing Ring	PP, PE, Zinc Plated Steel Ring, Ss Ring
Transport Package	Export Standard Packing
Specification	Size 1~Size 5
Trademark	Filterek, OEM
Origin	China
HS Code	5911900090
Production Capacity	60000pieces/Year

Packaging & Delivery

Package Size 500.00cm * 500.00cm * 500.00cm Package Gross Weight 20.000kg

Product Description

Finely Processed Oil Water Filtration Exclusive Custom Micron Filter Bags
In the market, there are two main types of common materials, one is general needle punched felt material, another typical material is mesh material which material of Nylon, polypropylene, and polyester. While some special melt blown material can only be provided by few professional companies.

PPSG & PESG are standard materials for Filterek, and both are the representative products of felt. As the filter products for liquid, its definition of micro rating is not that easy which counts on the thickness and the surface smooth of the felt, but on complex internal fiber proportioning. Filterek use nearly 30 kinds of fibers with different diameter, adopt advanced fiber mixture equipment to manufacture accurate micro rating needle felt. Due to the wider variety of the material and the smaller quantity of each product, compared with those mono-fiber products, the professional material price will be more expensive.

To reduce the users' cost, we particularly developed the economical products such as PPB & PEB according to some industries with considerate quantity. If the quantity of the order is big enough , the price can be low enough.

However, anyway, Filterek will secure that the materials we used in any application area are all 100% original raw material, and Filterek will strongly reject to adopt recycled material which may take security risk, as we can see which will produce poisonous substance that damage the stability of the products and do harm to public.

Filterek has extended the mesh materials, except common Nylon mesh, we also developed two mesh products with special application with painting grade , food and pharmaceutical grade. In painting and colorant process, the material must be silicon free, oil & grease free, and fiber free. In food and pharmaceutical process, some usual Nylon mesh products will be forbidden by the security. We strictly define different material application for customer special requirement. Also we can provide Polypropylene and Polyester monofilament products with richer chemical compatibility. All products for filtration adopts cross pointed fixed monofilament material instead of multifilament or uncross shot mesh products, which can gaining stable micro rating accuracy during filtration.

Polypropylene melt blown material is the decisive material for high-quality filter bags. No matter for absolute products or oil-adsorbent products, this technology is the most essential to make these products. Owing to Filterek's master of the basic material patented technology, our products can rapidly cover the international leading products market.

Filter Bag Code Identification

PPSG - Standard single layer polypropylene felt/Single side glazed/Nominal rating, Removal Efficiency>85%

PPEX- Life extended single layer polypropylene felt/Single side glazed/Nominal rating, Removal Efficiency>85%

PPX - Life extended multi layers polypropylene/Special fiber protective layer/Nominal rating, Removal Efficiency>85%

PPXG- Life extended double layers polypropylene felt /Outer side glazed/Nominal rating, Removal Efficiency>95%

PPAB- Polypropylene oil absorb and adsorb material/Alternate with FSI POMF series products/Nominal rating, Removal Efficiency>95%

PPMD-High removal efficiency and excellent oil absorb and adsorb polypropylene multi layers /Absolute rating/Removal Efficiency>98%

PPD - Special code for customer designation Polypropylene Multi-layers, Every code designed after special analysis of customer's process And the

configuration

APM- Polypropylene multi media/Absolute rating/Removal Efficiency>98%, APM300 alternate with EATON's 100 series products& APM900 alternate with

EATON's 500 series products

APTM- Polypropylene multi media/Absolute rating/Removal Efficiency>98%, APTM300 alternate with 3M's 100 series products& APTM900 alternate with

3M's 500 series products

BMAX- Polypropylene standard bag insert seamless cores for high removal efficiency and pre-filtration/Nominal rating, Removal Efficiency>95%, Alternate

with FSI's MAX series products.

BMOS-Polypropylene Seamless Bags with fiber protective layers outside/Absolute rating/Removal Efficiency>98%, Alternate with FSI's BOS series products.

PESG- Standard single layer polyester felt /Single side glazed/Nominal rating, Removal Efficiency>85%

PEEX- Life extended single layer polyester felt /Single side glazed/Nominal rating, Removal Efficiency>85%

PEX - Life extended multi layers polyester /Special fiber protective layer/Nominal rating, Removal Efficiency>85%

PEXG- Life extended double layers polypropylene felt /Outer side glazed/Nominal rating, Removal Efficiency>95%

PEB -Batch order single layer polyester felt /Single side glazed/Nominal rating, Removal Efficiency>85%

PED -Special code for customer designation Polyester Multi layers, Every code designed after special analysis of customer's process And the configuration

NLMO- Standard Nylon mesh for painting degree/Absolute rating/Removal Efficiency>95%

NLMP-Standard Nylon 66 mesh for food and pharmaceutical/Absolute rating/Removal Efficiency>95%

NLMB- Standard Nylon mesh/Absolute rating/Removal Efficiency>95%

NMD - Special code for customer designation Nylon mesh Multi layers

Every code designed after special analysis of customer's process And the configuration

PEMO- Standard Polyester mesh/Absolute rating/Removal Efficiency>95%

PPMO- Standard Polypropylene mesh/Absolute rating/Removal Efficiency>95%

ACBX- Granular Activated Carbon/Nominal rating, Removal Efficiency>85%

Specification

Available Material	PP Felt, PE Felt
Seal Ring Material	PP, PE, Zinc plated steel ring, Stainless steel ring
Seam type	Welded Seam, Stitched Seam
Micron Rating	PP: 1um~ 200um
	PE: 1um~ 200um
Size	1#: 7"x16"
	2#: 7"x32"
	3#: 4"x9"
	4#: 4"x15"
	5#: 6"x20"
Bottom Shape	Semi-Circle & V-Triangle
Others	Customize Available

Applications:
* Auto coating & paint
* Water purification & processing
* Pharmaceutical
* Food & beverage
* Bulk & fine chemicals
* Electronics

FAQ

1 What is the filtration effectiveness? 99%-99.99%2 What kind of terms and payment do you accept? Usually T/T

3: I am a small business owner, Can I buy from you? Yes, you are warmly welcomed. To grow with our customer is our goal. We would like to grow with you together. 4:Q: How should I place an order? Please kindly click" send inquiry" or "contact supplier", Then our sales engineer will recommend you suitable products for your selection also give some valuable suggestion for your selection.

5. Q: What is your general delivery time? Answer: Generally 20-30 days
