Basic Info.

Model NO.	PL-HS11L
Useful Life	12000hs
Rated Power	5W-95W
Application	Sterilization
Transport Package	50 PCS/CTN, Paper Carton Standard Export Packing
Specification	CE
Trademark	JL
Origin	Jiangsu, China
Production Capacity	100000 Piece/Pieces Per Month

Product Description

H-Model ultraviolet lamp germicidal lamp UV lamp living Aquarium cross-flow ultraviolet lampQuick Details

• Place of Origin: China (Mainland)
• Brand Name: Germicidal Lamp
• Model Number: UV Lamp
• Rated Power: 5W -95W
• Voltage: 220V
• Wavelength:: 254nm
• Longlife:: 12000hrs
• warranty:: 3years
• Tube Diameter: 13mm-17mm

Product description

Main models:PL-HS5L,PL-HS7L, PL-HS9L,PL-HS11L,PL-HS13L, PL-HS18L, PL-HS24L, PL-HS35L,PL-HS36L, PL-HS755L, PL-HS760L, PL-HS95L,

Technical Details of UV Germicida lamps of H-Model
Model No.	Dia	length	Power	Current	Volt	UVCW		Lamp cap	Lifetime
	mm	mm	W	mA	V	UVCW		/	HRS
PL-HS5L	13	85	5	180	34	12	1.1	G23/2G7	9000
PL-HS7L	13	115	7	175	47	20	1.5	G23/2G7	9000
PL-HS9L	13	145	9	170	60	23	2.4	G23/2G7	9000
PLHS911L	13	214	11	160	89	33	3.6	G23/2G7	9000
PL-HS13L	13	155	13	290	60	31	3.4	G23/2G7	9000
PL-HS18L	17	217	18	370	60	60	5.8	2G11	9000
PL-HS24L	17	317	24	350	87	90	7	2G11	9000
PL-HS35L	17	217	35	850	40	105	11	2G11	9000
PL-HS36L	17	410	36	440	105	120	12	2G11	9000
PL-HS55L	17	530	55	540	103	170	18	2G11	9000
PL-HS60L	17	410	60	670	118	170	18	2G11	9000
PL-HS95L	17	530	95	950	100	305	33	2G11	9000

Features and advantages
1. There is protective film in the inner wall of the tube, Uv output attenuates<15% in service period;
2. Special starter is in G23 lamp cap, jump quickly
3. Apply amalgam lamp technology of RUILANG/CREATOR, it is the best performance and strongest ultraviolet output of H-Model ultraviolet germicidal lamp in the market now.

Application
Aquatic breeding disinfection;
Pond water disinfection
Air treatment disinfection
Home drinking water disinfection
Air purifying disinfection
Purifier
