Basic Info.

Model NO.	DGRH-ETL-A01
Transport Package	Carton
Trademark	RUIHE / DR. AIRE
Origin	Dongguang, China
HS Code	8539490000
Production Capacity	10000 Unit/Month

Product Description

UV-C Germicidal Lamp For HVAC Coil Disinfection

This product is designed to help disinfect the internal surfaces of heating, ventilation, and air conditioning systems. Bacteria, viruses and mold that are in the air stream that passes through the system will also be reduced. The result is an improved level of indoor air quality for occupants and improved system hygiene.

The ultraviolet (UV-C) radiation (254 nanometers) which has been proven effective in arresting microorganisms such as viruses, bacteria, yeast and molds. This process either destroys the micro-organism DNA or neutralizes its ability to reproduce.

HVAC Coils Disinfection

• Germicidal UV lamp system helps cut energy and operational costs.

• UV destroys surface biofilm which is prevalent in air conditioning systems and can lead to a host of indoor air quality problems.

• UV also destroys airborne viruses and micro-organisms that circulate through these systems.

• Helps reduce staff absenteeism and improves productivity. High output Ultra-violet positioned irradiating the fins of the coil, will keep it free of biofilm and other contaminated build up. Reduces the high maintenance expense of manual cleaning.

• Ultra-violet is safe, effective, cost cutting and automatic, cleaning in hard to access locations. Build up on coils also causes higher running costs through inefficiency.

Model	UV length (mm)	UV wave (nm)	Total Power (W)	Lifespan (hours)	Power Supply
DGRH-ETI-C01	436	254	25	10, 000	230VAC 50~60Hz
DGRH-ETI-C02	589	254	30	10, 000	230VAC 50~60Hz
DGRH-ETI-C03	843	254	75	10, 000	230VAC 50~60Hz
DGRH-ETI-C04	1,148	254	120	10, 000	230VAC 50~60Hz
DGRH-ETI-C05	1,554	254	150	10, 000	230VAC 50~60Hz
